Square Gooseneck Trailer Coupler 25K 4.5″ Outer 4″ Inner 32″ Tall 2-5/16″

One New Aftermarket Replacement 25K Square Gooseneck Coupler with Pin

Features:

• Easy-Grip Locking Handle Is Accessible from Any Position
• Self-Centering Locking Plate Lets You Miss the Ball by More Than an Inch
• Tight Ball Fit Reduces Jarring When Changing Speeds or on Rough Roads
• Heavy-Duty High-Strength Fabricated Steel Components Are as Strong as Heavy Cast Iron but Lighter and Less Brittle
• User-Friendly Design Enables Quick, Easy Hookup and Release
• Locking Handle Cover Protects Working Parts
• Cam Locking Pin Affords Easy Vertical Adjustment
• Pinch Bolt Design

Tech Info:

• Ball Size: 2-5/16″
• Capacity: 25,000 lbs
• Range of Adjustment: 8″
• Inner Tube Diameter: 4″ OD
• Outer Tube Diameter: 4-1/2″ OD
• Retracted Height: 32″
• Extended Height: 40″
• Set Screw Diameter: 3/4″

Replaces Part Numbers: 0289600300Additional Information: Ball Size: 2-5/16″Capacity: 25,000 lbsRange of Adjustment: 8″Inner Tube Diameter: 4″ ODOuter Tube Diameter: 4-1/2″ ODRetracted Height: 32″Extended Height: 40″Set Screw Diameter: 3/4″
